Featuring

1.can precisely bend diameter 1/2”-4”pipes .

2.Includes standard bending dies , tripod stands and 1.8m high pressure oil hose .

3.Separable type, more flexible tooperate.

All parts and machine will be put in a plywood case .

Specifications

Model:HHW-2F

Pipe wall thickness :2.75-4.5mm

Bending dies:  1/2",3/4",1",1 1/4",1 1/2",2"

Max stroke :250mm

-----------

Model:HHW-3F

Pipe wall thickness :2.75-5mm

Bending dies:  1/2",3/4",1",1 1/4",1 1/2",2",2 1/2",3"

Max stroke :320mm

----------

Model:HHW-4F

Pipe wall thickness :2.75-6mm

Bending dies:  1/2",3/4",1",1 1/4",1 1/2",2",2 1/2",3",4"

Max stroke :370mm
